2SK1818 250V 20A N-Channel Power MOSFET

The 2SK1818, 2SK-1818, K1818, 1818 is a 250V 20A 50W N-Channel Power MOSFET TO-220 Package, With User Guide Manufactured By SANYO.

Features:

1. Type Designator: 2SK1818-MR
2. Type of Transistor: MOSFET
3. Type of Control Channel: N -Channel
4. Maximum Power Dissipation (Pd): 50 W
5. Maximum Drain-Source Voltage |Vds|: 250 V
6. Maximum Gate-Source Voltage |Vgs|: 20 V
7. Maximum Drain Current |Id|: 20 A
8. Maximum Junction Temperature (Tj): 150 °C
9. Rise Time (tr): 50 nS
10. Drain-Source Capacitance (Cd): 240 pF
11. Maximum Drain-Source On-State Resistance (Rds): 0.16 Ohm

Packing List:

1Pc * 2SK1818 250V 20A N-Channel Power MOSFET
